• 9-36 VDC Operating Voltage (Applicable to 12/24 V Systems)
  • 6 Digital Input
  • 2 Half-Bridge Output  -2,5/10A
  • 1xCAN Interface (Protocol SAE J1939)
  • Wake Up via CAN and Digital Input
  • 120 mm x 100 mm x 42 mm Dimensions
  • -40 °C ~ +85 °C Operating Temperature
Categories: , , Tag: Product ID: 3251


oMux.6×2, a part of the Multiplexer product family, is a Body Control Unit that fulfills essential control functions such as door control, signaling, lamp operation, wiper motor control, air conditioner motor control, and window raising/lowering in vehicles. It can be installed in different parts of the vehicle and provide real time information via CAN-Bus communication interface.

Due to its capability to execute simultaneous operations, it provides the most cost-effective and economical solution for the vehicle. It can operate 15 oMux devices on the same CAN-Bus with identical embedded software due to its master/slave operation capability. This allows seamless integration and efficient management of multiple oMux units within the vehicle system.

With the user-friendly oMux.Designer development GUI application, one can effortlessly create user-defined scenarios using functional block diagrams. Real-time software updates, diagnostics, and software retrieval processes can be performed via CAN-Bus, ensuring efficient operations and hassle-free maintenance. With the ability of the CAN-Bus communication interface, embedded software updates can be transmitted to all devices concurrently without uninstalling them from the vehicle.

oMux.6×2 – Product Brochure
